CPSN-SSI-4C

Overview / Features

This product is an expansion I/O module that adds a thermocouple interface to the CPU unit of the CONPROSYS nano series.Four channels of differential inputs are provided for one module.

• Compatible with various types of thermocouple inputs
  • This product is compatible with a wide range of thermocouple input types such as J(IEC60584-1), K(IEC60584-1), E(IEC60584-1), N(IEC60584-1), R(IEC60584-1), S(IEC60584-1), and T(IEC60584-1).
• Cold junction compensation function
  • As cold junction compensation is integrated in the product, there is no need to install a temperature sensor for cold junction compensation externally, and temperature can be measured simply by connecting a thermocouple.
• LED indicator for status check
  • The error status of thermocouple such as disconnected, not-connected, or sensor circuit trouble can be checked with the LED indicator.
• Easy installation and removal
  • This product can be installed in and removed from the CPU unit without any tools.
• Adaptable to a wide range of temperature between -20 and +60°C
  • The product is capable of operating in the temperature between -20 and + 60°C. It can be installed in the various environments.
• No electrolytic capacitor
  • Without an electrolytic capacitor, which has a limited life, we are creating the product with a longer life.
