FXS5000

Overview / Features

This product is a wireless LAN access point that complies with the wireless LAN standard IEEE802.11ax/ac/n/a/b/g and supports a wide input power supply (5 – 30VDC).It has various functions such as smart roaming (duplication) and mesh Wi-Fi network support, and has high security, stable communication, and excellent maintainability.By switching the mode, it can be operated not only as an access point (parent station) but also as a station (child station) or repeater. It can be used as an access point or a repeater. In addition, in “dual station mode”, the 5GHz interface and the 2.4GHz interface can be used simultaneously.It has a lightweight and compact design, and can be installed smartly using the included magnets and tapping screws. It is also equipped with a cover to protect the connector and a security slot to prevent theft.

• Wi-Fi 6 (IEEE 802.11ax) compliant high-speed, low-latency communication 2.4GHz and 5GHz can be used simultaneously
  • The effective throughput has been significantly improved, and data transmission and reception has been accelerated to 2.8 times (2.4Gbps) faster than Wi-Fi 5 (800Mbps). New technologies such as OFDMA (Orthogonal Frequency Division Multiple Access) and MU-MIMO (Multi-User MIMO) have been implemented, greatly improving the throughput degradation and delays that occurred when using many child stations simultaneously. The use of the conventional 2.4GHz and 5GHz bands has reduced radio interference, allowing for a faster and more stable communication environment. The 2.4GHz and 5GHz bands can also be used simultaneously.
• Mesh Wi-Fi network
  • It is equipped with a wireless mesh network function that configures one network group (ESSID) with multiple access points in a mesh-like communication path. Even if a failure occurs somewhere in the communication path, the optimal alternative path is automatically secured to maintain communication connection, making it possible to build a network that is resistant to failure. Since the access points are also connected wirelessly, the communication area can be easily expanded by simply increasing the number of access points.
• Smart Roaming (Dual)
  • It is equipped with a “dual station mode” that expands communication from one wireless connection to two (duplication). Even if one wireless connection is interrupted, the other wireless connection is available, so data communication will not be interrupted during roaming. Contec’s unique tuning in pursuit of “uninterrupted wireless LAN” has achieved high-level roaming.
• Equipped with WSL, a proprietary encryption technology that can be used in conjunction with WPA3/WPA2/WPA and WEP
  • In addition to the advanced security standards WPA3/WPA2/WPA and IEEE802.1X authentication, it is equipped with the proprietary encryption technology WSL that can be used in conjunction with these.It also supports MAC address filtering and ESSID hiding.
• Equipped with various functions such as VLAN and virtual AP function
  • It is equipped with a VLAN function for constructing a virtual network, and a virtual AP function that allows one AP to operate as multiple virtual APs and set different security settings. It also has the ability to store large amounts of event logs. *The VLAN function will be supported by a firmware upgrade.
• Can be installed not only on a flat surface, but also on walls, ceilings, etc.
  • The included mounting bracket allows you to install the device in a location with good visibility and good signal transmission (on a wall or ceiling, etc.).
