LPC-1800-G

Overview / Features

This product is a BTO industrial computer that support an 13th generation Intel® Core™ processor series or 12th generation Celeron® processor G6900T. The Intel® Q670 chipset with DDR5 memory (128GB) provides advanced computing and graphical performance. This product features a variety of interfaces such as one each port of DVI-I, HDMI, DisplayPort, eight USB 3.2 Gen1 (USB 3.0) ports (front: 2, rear: 6), four USB 2.0 ports (front: 2), one serial port (RS-232C/422A/485×1), two 2.5BASE-T ports, and one 1000BASE-T port, which can be used in a wide range of embedded applications such as general-purpose PC OS-based controllers and information terminals. Expansion slots : PCI-Express 3.0(x16) slot x1, PCI-Express 3.0(x4) slot x2, PCI slots x1.

• Compatible with Intel® Core ™ processor series Raptor Lake
  • The product supports an 13th-generation Intel® Core ™ processor and 12th-generation Celeron® processor G6900T and greatly realizes lower-power consumption while ensuring fine performance of operation tasks and drawing. Adopting embedded-type CPU contributes to a stable supply.
• High-performance graphics with CPU embedded type
  • Full HD video can be smoothly played with the Intel® UHD Graphics 710/730/770. It also supports full HD output of the three-screen with the DVI-I, DisplayPort and HDMI.
• Rich variety of interfaces to expand your peripherals freely
  • Interfaces including DVI-I, HDMI, DisplayPort, 2.5GBASE-T x 2, 1000BASE-T x 1, USB 3.2 Gen1 (USB 3.0) x 8, USB 2.0 x 2, serial port (RS-232C/RS-422A/RS-485 x 1), and audio are provided.
• The identical dimensions enable easy replacement with the LPC-1700 series
  • In order to replace the system with ease, this product has the same physical dimensions as the LPC-1700 series.
