With its capacitive touchscreen and Android 8.1 operating system, the SD55 Lynx UHF is everything you’ve asked for in a mobile computer, and more. Equipped with a UHF Antenna, this device can easily read RFID tags hard-to-reach areas of your stockroom.
The SD55 Lynx MD is part of the SD55 Android Mobile Computer Series. With optimized solutions for Logistical and Healthcare applications, the SD55 Series consists of different models that slot into your industry scanning needs.
Supports. All major 1D and 2D barcode symbologies.
Software. Built on Android 8.1
Display. 5.5 inch (1440 x 720) 5 point capacitive touch screen.
Processor. Octa-Core 2.0 GHz CPU.
Offers. Wi-Fi 802.11 a/b/g/n (2.4GHz & 5GHz), Bluetooth 5.0, camera, NFC, GSM, WCDMA.
| Type | SD55UHF-C |
|---|---|
| Operating System |
Android 8.1 |
| Size | 150(h) x 72.5(w) x 16.5(d) mm |
| Weight | 290g (with battery) |
| PTT ready | Yes (3rd party software required) |
| LWP ready | No |
| Bluetooth® | 4.1 BLE |
| Frequencies |
FDD LTE B1/B3/B5/B7/B8 TDD LTE B38/B39/B40/B4 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8 CDMA1x/CDMA2000 BC0/BC1 |
| Wi-Fi® | IEEE 802.11 a/b/g/n/ac 2.4G 5G dual frequency |
| RFID | ISO14443A/B, ISO15693, NFC reading distance: 0~5cm; UHF: ISO18000-6C, Euro frequency (865MHz – 867MHz), Antenna: 1.5dBi ceramic antenna, Power: working voltage 3.6-5V,RF output 5dBm to 30dBm(1W), 1dbm adjustable, Standby power consumption: about 0.25W, maximum 4W(typical 3.5W), Identification range: indoor >5m, outdoor open environment >3m, Group read rate: >30 tags per second, Inventory speed: >30 tags/sec |
| Location | GPS+BD+GLONASS |
| Display | 5.5″, IPS highlight screen |
| Processor | Octa-Core 2.0 GHz |
| Memory | 4GB RAM | 64GB internal memory |
| Micro-SD | Yes |
| Camera | 13M Pixels AF Rear camera; High brightness LED flash, 5M Pixels FF Front camera |
| Battery | 5800mAh |
| Operation | IP65 dust-/waterproof | 1.5m drop to concrete | usable from -20 °C to +55 °C |
